Forklift Starter and Alternator

Forklift Starters and Alternators - A starter motors today is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor together with a starter solenoid mounted on it. When current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion utilizing the starter ring gear that is found on the engine flywheel.

The solenoid closes the high-current contacts for the starter motor, that begins to turn. Once the engine starts, the key operated switch is opened and a spring inside the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in only a single direction. Drive is transmitted in this particular way via the pinion to the flywheel ring gear. The pinion remains engaged, like for example because the driver did not release the key when the engine starts or if the solenoid remains engaged for the reason that there is a short. This causes the pinion to spin independently of its driveshaft.

This aforementioned action stops the engine from driving the starter. This is actually an essential step in view of the fact that this kind of back drive will enable the starter to spin so fast that it could fly apart. Unless adjustments were made, the sprag clutch arrangement will prevent utilizing the starter as a generator if it was made use of in the hybrid scheme discussed prior. Typically an average starter motor is designed for intermittent use that would stop it being used as a generator.

The electrical components are made so as to operate for more or less 30 seconds so as to avoid overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are meant to save cost and weight. This is the reason the majority of owner's guidebooks meant for automobiles recommend the operator to stop for at least 10 seconds right after each and every 10 or 15 seconds of cranking the engine, whenever trying to start an engine which does not turn over instantly.

During the early part of the 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was used. The Bendix system works by placing the starter drive pinion on a helically cut driveshaft. Once the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

The development of Bendix drive was made during the 1930's with the overrunning-clutch design referred to as the Bendix Folo-Thru drive, made and introduced in the 1960s. The Folo-Thru drive has a latching mechanism together with a set of flyweights in the body of the drive unit. This was better in view of the fact that the standard Bendix drive used to be able to disengage from the ring as soon as the engine fired, though it did not stay functioning.

Once the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be avoided prior to a successful engine start.
